10.5: Horizontal Winds

• Roland Stull
• University of British Columbia

When air accelerates to create wind, forces that are a function of wind speed also change. As the winds continue to accelerate under the combined action of all the changing forces, feedbacks often occur to eventually reach a final wind where the forces balance. With a zero net force, there is zero acceleration. Such a final, equilibrium, state is called steady state: \(\ \begin \frac=0, \quad \frac=0\tag\end\) Caution: Steady state means no further change to the non-zero winds. Do not assume the winds are zero. Under certain idealized conditions, some of the forces in the equations of motion are small enough to be neglected. For these situations, theoretical steady-state winds can be found based on only the remaining larger-magnitude forces. These theoretical winds are given special names, as listed in Table 10-4. These winds are examined next in more detail. As we discuss each theoretical wind, we will learn where we can expect these in the real atmosphere.

Table 10-4. Names of idealized steady-state horizontal winds, and the forces that govern them.
Wind Name
Geostrophic	•	•
Gradient	•	•	•
Atm.Bound. Layer	•	•	•
ABL Gradient	•	•	•	•
Cyclostrophic	•	•
Inertial	•	•
Antitriptic	•	•

10.5.1. Geostrophic Wind

For special conditions where the only forces are Coriolis and pressure-gradient (Fig. 10.8), the resulting steady-state wind is called the geostrophic wind, with components (U_g , V_g). For this special case, the only terms remaining in, eqs. (10.23) are: \(\ \begin 0=-\frac \cdot \frac+f_ \cdot V\tag\end\) \(\ \begin 0=-\frac \cdot \frac-f_ \cdot u\tag\end\) Define U ≡ U_g and V ≡ V_g in the equations above, and then solve for these wind components: \(\ \begin U_=-\frac<\rho \cdot f_> \cdot \frac\tag\end\) \(\ \begin V_=+\frac<\rho \cdot f_> \cdot \frac\tag\end\) where f_c = (1.4584x10 –4 s –1 )·sin(latitude) is the Coriolis parameter, ρ is air density, and ∆P/∆x and ∆P/∆y are the horizontal pressure gradients.

Sample Application Find geostrophic wind components at a location where ρ = 1.2 kg m –3 and f_c = 1.1x10 –4 s –1 . Pressure decreases by 2 kPa for each 800 km of distance north. Find the Answer Given: f_c =1.1x10 –4 s –1 , ∆P= –2 kPa, ρ=1.2 kg m –3 , ∆y=800 km. Find: (U_g , V_g) = ? m s –1 But ∆P/∆x = 0 implies V_g = 0. For Ug, use eq. (10.26a): \(U_=\frac <\left(1.2 \mathrm/ \mathrm^\right) \cdot\left(1.1 \times 10^ s^\right)> \cdot \frac<(-2 \mathrm)><(800 \mathrm)>=18.9 \mathrm^\) Check: Physics & units OK. Agrees with Fig. 10.10. Exposition: As the pressure gradient accelerates air northward, Coriolis force turns it toward the east.

Real winds are nearly geostrophic at locations where isobars or height contours are relatively straight, for altitudes above the atmospheric boundary layer. Geostrophic winds are fast where isobars are packed closer together. The geostrophic wind direction is parallel to the height contours or isobars. In the N. (S.) hemisphere the wind direction is such that low pressure is to the wind’s left (right), see Fig. 10.9. The magnitude G of the geostrophic wind is: \(\ \begin G=\sqrt^+V_^>\tag\end\) If ∆d is the distance between two isobars (in the direction of greatest pressure change; namely, perpendicular to the isobars), then the magnitude (Fig. 10.10) of the geostrophic wind is: \(\ \begin G=\left|\frac> \cdot \frac\right|\tag\end\) Above sea level, weather maps are often on isobaric surfaces (constant pressure charts), from which the geostrophic wind (Fig. 10.10) can be found from the height gradient (change of height of the isobaric surface with horizontal distance): \(\ \begin U_=-\frac<|g|>> \cdot \frac\tag\end\) \(\ \begin V_=+\frac<|g|>> \cdot \frac\tag\end\) where the Coriolis parameter is f_c , and gravitational acceleration is |g| = 9.8 m·s –2 . The corresponding magnitude of geostrophic wind on an isobaric chart is: \(\ \begin G=\left|\frac> \cdot \frac\right|\tag\end\)

Sample Application Find the geostrophic wind for a height increase of 50 m per 200 km of distance toward the east. Assume, f_c = 0.9x10 –4 s –1 . Find the Answer Given: ∆x = 200 km, ∆z = 50 m, f_c = 0.9x10 –4 s –1 . Find: G = ? m s –1 . No north-south height gradient, thus U_g = 0. Apply eq. (10.29b) and set G = V_g : \(V_=+\frac<|g|>> \cdot \frac=\left(\frac^>^>\right) \cdot\left(\frac>>\right)=27.2 \mathrm^\) Check: Physics & units OK. Agrees with Fig. 10.10. Exposition: If height increases towards the east, then you can imagine that a ball placed on such a surface would roll downhill toward the west, but would turn to its right (toward the north) due to Coriolis force.

INFO • Approach to Geostrophy

How does an air parcel, starting from rest, approach the final steady-state geostrophic wind speed G sketched in Fig. 10.8? Start with the equations of horizontal motion (10.23), and ignore all terms except the tendency, pressuregradient force, and Coriolis force. Use the definition of geostrophic wind (eqs. 10.26) to write the resulting simplified equations as: \(\Delta U / \Delta t=-f_ \cdot\left(V_-V\right)\)
\(\Delta V / \Delta t=f_ \cdot\left(U_-U\right)\) Next, rewrite these as forecast equations: \(U_>=U_>-\Delta t \cdot f_ \cdot\left(V_-V_>\right)\)
\(V_>=V_>+\Delta t \cdot f_ \cdot\left(U_-U_>\right)\) Start with initial conditions (U_old, V_old) = (0, 0), and then iteratively solve the equations on a spreadsheet to forecast the wind. For example, suppose ∆P = 1 kPa, f_c = 10 –4 s –1 , ∆x = 500 km, ρ = 1 kg m –3 , where we would anticipate the wind should approach (U_g, V_g) = (0, 20) m s –1 . The actual evolution of winds (U, V) and air parcel position (X, Y) are shown in Figs. below. Surprisingly, the winds never reach geostrophic equilibrium, but instead rotate around the geostrophic wind. This is called an inertial oscillation, with period of 2·π/f_c. For our case, the period is 17.45 h. Twice this period is called a pendulum day. The net result in the figure below is that the wind indeed moves at the geostrophic speed of 20 m s–1 to the north (≈ 1250 km in 17.45 h), but along the way it staggers west and east with an additional ageostrophic (non-geostrophic) part. Inertial oscillations are sometimes observed at night in the atmospheric boundary layer, but rarely higher in the atmosphere. Why not? (1) The ageostrophic component of wind (wind from the East in this example) moves air mass, and changes the pressure gradient. (2) Friction damps the oscillation toward a steady wind.

If the geopotential Φ = |g|·z is substituted in eqs. (10.29), the resulting geostrophic winds are: \(\ \begin U_=-\frac> \cdot \frac\tag\end\) \(\ \begin V_=\frac> \cdot \frac\tag\end\)

10.5.2. Gradient Wind

If there is no turbulent drag, then winds tend to blow parallel to isobar lines or height-contour lines even if those lines are curved. However, if the lines curve around a low-pressure center (in either hemisphere), then the wind speeds are subgeostrophic (i.e., slower than the theoretical geostrophic wind speed). For lines curving around high-pressure centers, wind speeds are supergeostrophic (faster than theoretical geostrophic winds). These theoretical winds following curved isobars or height contours are known as gradient winds. Gradient winds differ from geostrophic winds because Coriolis force F_CF and pressure-gradient force F_PG do not balance, resulting in a non-zero net force F_net. This net force is called centripetal force, and is what causes the wind to continually change direction as it goes around a circle (Figs. 10.11 & 10.12). By describing this change in direction as causing an apparent force (centrifugal), we can find the equations that define a steady-state gradient wind: \(\ \begin 0=-\frac \cdot \frac+f_ \cdot V+s \cdot \frac \tag\end\) \(\ \begin 0=-\frac \cdot \frac-f_ \cdot U-s \cdot \frac\tag\end\) Because the gradient wind is for flow around a circle, we can frame the governing equations in radial coordinates, such as for flow around a low: \(\ \begin \frac \cdot \frac=f_ \cdot M_+\frac\tag\end\) where R is radial distance from the center of the circle, f_c is the Coriolis parameter, ρ is air density, ∆P/∆R is the radial pressure gradient, and M_tan is the magnitude of the tangential velocity; namely, the gradient wind. By re-arranging eq. (10.32) and plugging in the definition for geostrophic wind speed G, you can get an implicit solution for the gradient wind M_tan: \(\ \begin M_<\mathrm>=G \pm \frac \tag\end\) In this equation, use the + sign for flow around highpressure centers, and the – sign for flow around lows (Fig. 10.13).

Sample Application What radius of curvature causes the gradient wind to equal the geostrophic wind? Find the Answer Given: M_tan = G Find: R = ? km Use eq. (10.33), with M_tan = G: G = G ± G 2 /( f_c·R) This is a valid equality G = G only when the last term in eq. (10.33) approaches zero; i.e., in the limit of R = ∞ . Check: Eq. (10.33) still balances in this limit. Exposition: Infinite radius of curvature is a straight line, which (in the absence of any other forces such as turbulent drag) is the condition for geostrophic wind.

INFO • The Rossby Number

The Rossby number (R_o) is a dimensionless ratio defined by \(R o=\frac \cdot L> \quad\) or \(\quad R o=\frac \cdot R>\) where M is wind speed, f_c is the Coriolis parameter, L is a characteristic length scale, and R is radius of curvature. In the equations of motion, suppose that advection terms such as U·∆U/∆x are order of magnitude M 2 /L, and Coriolis terms are of order f_c·M. Then the Rossby number is like the ratio of advection to Coriolis terms: (M 2 /L) / (f_c·M) = M/(f_c·L) = Ro. Or, we could consider the Rossby number as the ratio of centrifugal (order of M 2 /R) to Coriolis terms, yielding M/(f_c·R) = Ro. Use the Rossby number as follows. If Ro < 1, then Coriolis force is a dominant force, and the flow tends to become geostrophic (or gradient, for curved flow). If Ro >1, then the flow tends not to be geostrophic. For example, a midlatitude cyclone (low-pressure system) has approximately M = 10 m s –1 , f_c = 10 –4 s –1 , and R = 1000 km, which gives Ro = 0.1 . Hence, midlatitude cyclones tend to adjust toward geostrophic balance, because Ro < 1. In contrast, a tornado has roughly M = 50 m s –1 , f_c = 10 –4 s –1 , and R = 50 m, which gives Ro = 10,000, which is so much greater than one that geostrophic balance is not relevant.

Eq. (10.33) is a quadratic equation that has two solutions. One solution is for the gradient wind Mtan around a cyclone (i.e., a low): \(\ \begin M_<\mathrm>=0.5 \cdot f_ \cdot R \cdot[-1+\sqrt >]\tag\end\) The other solution is for flow around an anticyclone (i.e., a high): \(\ \begin M_<\mathrm>=0.5 \cdot f_ \cdot R \cdot[1-\sqrt >]\tag\end\) To simplify the notation in the equations above, let \(\ \begin R o_=\frac \tag\end\) where we can identify (Ro_c) as a “curvature” Rossby number because its length scale is the radius of curvature (R). When Ro_c is small, the winds are roughly geostrophic; namely, pressure gradient force nearly balances Coriolis force. [CAUTION: In later chapters you will learn about a Rossby radius of deformation, which is distinct from both Ro_c and R.] For winds blowing around a low, the gradient wind is: \(\ \begin M_<\mathrm>=\frac<2 \cdot R o_> \cdot\left[-1+\left(1+4 \cdot R o_\right)^\right]\tag\end\) and for winds around a high) the gradient wind is: \(\ \begin M_<\mathrm>=\frac<2 \cdot R o_> \cdot\left[1-\left(1-4 \cdot R o_\right)^\right]\tag\end\) where G is the geostrophic wind. While the differences between solutions (10.36a & b) appear subtle at first glance, these differences have a significant impact on the range of winds that are physically possible. Any value of Ro_c can yield physically reasonable winds around a low-pressure center (eq. 10.36a). But to maintain a positive argument inside the square root of eq. (10.36b), only values of Ro_c ≤ 1/4 are allowed for a high. Thus, strong radial pressure gradients with small radii of curvature, and strong tangential winds can exist near low center. But only weak pressure gradients with large radii of curvature and light winds are possible near high-pressure centers (Figs. 10.14 and 10.15). To find the maximum allowable horizontal variations of height z or pressure P near anticyclones, use Ro_c = 1/4 in eq. (10.35) with G from (10.29c) or (10.28): \(\ \begin z=z_-\left(f_^ \cdot R^\right) /(8 \cdot|g|)\tag\end\) or \(\ \begin P=P_-\left(\rho \cdot f_^ \cdot R^\right) / 8\tag\end\) where the center pressure in the high (anticyclone) is P_c , or for an isobaric surface the center height is z_c, the Coriolis parameter is f_c , |g| is gravitational acceleration magnitude, ρ is air density, and the radius from the center of the high is R (see Fig. 10.14). Figs. 10.14 and 10.15 show that pressure gradients, and thus the geostrophic wind, can be large near low centers. However, pressure gradients, and thus the geostrophic wind, must be small near high centers. This difference in geostrophic wind speed G between lows and highs is sketched in Fig. 10.16. The slowdown of gradient wind M_tan (relative to geostrophic) around lows, and the speedup of gradient wind (relative to geostrophic) around highs is also plotted in Fig. 10.16. The net result is that gradient winds, and even atmospheric boundarylayer gradient winds M_ABLG (described later in this chapter), are usually stronger (in an absolute sense) around lows than highs. For this reason, low-pressure centers are often windy.

Sample Application If G = 10 m s –1 , find the gradient wind speed & Ro_c, given f_c = 10 –4 s –1 and a radius of curvature of 500 km? Find the Answer Given: G = 10 m s –1 , R = 500 km, f_c = 10 –4 s –1 Find: M_tan = ? m s –1 , Ro_c = ? (dimensionless) Use eq. (10.34a): M_tan = 0.5 · (10 -4 s -1 ) ·(500000m)· \([-1+\sqrt <\left(10^<-4>s^\right) \cdot(500000 m)>>]=\underline<8.54 m s^>\) Use eq. (10.35): \(R o_=\frac <(10 \mathrm/ \mathrm)> <\left(10^<-4>\mathrm^\right) \cdot\left(5 \times 10^ \mathrm\right)>=\underline\) Check: Physics & units are reasonable. Exposition: The gradient wind is slower than geostrophic and is in geostrophic balance.

10.5.3. Atmospheric-Boundary-Layer Wind

If you add turbulent drag to winds that would have been geostrophic, the result is a subgeostrophic (slower-than-geostrophic) wind that crosses the isobars at angle (α) (Fig. 10.17). This condition is found in the atmospheric boundary layer (ABL) where the isobars are straight. The force balance at steady state is: \(\ \begin 0=-\frac \cdot \frac+f_ \cdot V-w_ \cdot \frac>\tag\end\) \(\ \begin 0=-\frac \cdot \frac-f_ \cdot U-w_ \cdot \frac>\tag\end\) Namely, the only forces acting for this special case are pressure gradient, Coriolis, and turbulent drag (Fig. 10.17). Replace U with U_ABL and V with V_ABL to indicate these winds are in the ABL. Eqs. (10.38) can be rearranged to solve for the ABL winds, but this solution is implicit (depends on itself): \(\ \begin U_=U_-\frac \tag\end\) \(\ \begin V_=V_+\frac \tag\end\) where (U_g, V_g) are geostrophic wind components, f_c is Coriolis parameter, z_i is ABL depth, and w_T is the turbulent transport velocity. You can iterate to solve eqs. (10.39). Namely, first you guess a value for V_ABL to use in the right side of the first eq. Solve eq. (10.39a) for U_ABL and use it in the right side of eq. (10.39b), which you can solve for V_ABL. Plug this back into the right side of eq. (10.39a) and repeat this procedure until the solution converges (stops changing very much). The magnitude of the boundary-layer wind is: \(\ \begin M_=\left[U^ A B L+V^ A B L\right]^\tag\end\) For a statically neutral ABL under windy conditions, then w_T = C_D·M_ABL, where C_D is the drag coefficient (eq. 10.21). For most altitudes in the neutral ABL, an approximate but explicit solution is: \(\ \begin U_ \approx\left(1-0.35 \cdot a \cdot U_\right) \cdot U_-\left(1-0.5 \cdot a \cdot V_\right) \cdot a \cdot V_ \cdot G\tag\end\) \(\ \begin V_ \approx\left(1-0.5 \cdot a \cdot u_\right) \cdot a \cdot G \cdot U_+\left(1-0.35 \cdot a \cdot V_\right) \cdot V_\tag\end\) where the parameter is a = C_D/(f_c·z_i ), G is the geostrophic wind speed and a solution is possible only if a·G < 1. If this condition is not met, or if no reasonable solution can be found using eqs. (10.41), then use the iterative approach described in the next section, but with the centrifugal terms set to zero. Eqs. (10.41) do not apply to the surface layer (bottom 5 to 10% of the neutral boundary layer). If the ABL is statically unstable (e.g., sunny with slow winds), use w_T = b_D·w_B (see eq. 10.22). Above the surface layer there is an exact solution that is explicit: \(\ \begin U_=c_ \cdot\left[U_-c_ \cdot V_\right]\tag\end\) \(\ \begin V_=c_ \cdot\left[V_+c_ \cdot U_\right]\tag\end\) where \(c_=\frac \cdot w_> ,\) and \(c_=\frac<\left[1+c_^\right]>\) The factors in c₁ are given in the “Forces” section. In summary, both wind-shear turbulence and convective turbulence cause drag. Drag makes the ABL wind slower than geostrophic (subgeostrophic), and causes the wind to cross isobars at angle α such that it has a component pointing to low pressure.

Sample Application For statically neutral conditions, find the winds in the boundary layer given: z_i = 1.5 km, U_g = 15 m s –1 , V_g = 0, f_c = 10 –4 s –1 , and C_D = 0.003. What is the crossisobar wind angle? Find the Answer Given: z_i = 1.5 km, U_g = 15 m s –1 , V_g = 0, f_c = 10 –4 s –1 , C_D = 0.003. Find: V_ABL =? m s –1 , U_ABL =? m s –1 , M_ABL =? m s –1 , α = ? ° First: G =(U_g 2 + V_g 2 ) 1/2 = 15 m s –1 . Now apply eq.(10.41) \(a=\frac <\left(10^<-4>\mathrm^\right) \cdot(1500 \mathrm)>=0.02 \mathrm / \mathrm\) Check: a·G = (0.02 s m –1 )·(15 m s –1 ) =0.3 (is < 1. Good.) U_ABL=[1–0.35·(0.02s m –1 )·(15m s –1 )]·(15m s –1 )≈13.4m s –1 V_ABL=[1–0.5·(0.02s m –1 )·(15m s –1 )]· (0.02s m –1 )·(15m s –1 )·(15m s –1 ) ≈ 3.8 m s –1 \(M_=\sqrt=\sqrt<13.4^+3.8^>=13.9 \mathrm^\) Isobars are parallel to the geostrophic wind. Thus, the cross-isobar angle is: α =tan –1 (V_ABL/U_ABL) = tan –1 (3.8/13.4) = 15.8° . Check: Physics & units are reasonable. Exposition: Drag both slows the wind (13.4 m s –1 ) in the boundary layer below its geostrophic value (15 m s –1 ) and turns it at a small angle (15.8°) towards low pressure. Given N. Hem. (because of the positive Coriolis parameter), the ABL wind direction is 254.2°.

Sample Application For statically unstable conditions, find winds in the ABL given V_g = 0, U_g = 5 m s –1 , w_B = 50 m s –1 , z_i = 1.5 km, b_D = 1.83x10 –3 , and f_c = 10 –4 s –1 . What is the crossisobar wind angle? Find the Answer Given: (use convective boundary layer values above) Find: M_ABL =? m s –1 , V_ABL =? m s –1 , U_ABL =? m s –1 , α =?° Apply eqs. (10.42): \(c_=\frac<\left(1.83 \times 10^<-3>\right) \cdot(50 \mathrm / \mathrm)> <\left(10^<-4>\mathrm^\right) \cdot(1500 \mathrm)>=0.61(\) dimensionless) c₂ = 1/[1+(0.61) 2 ] = 0.729 (dimensionless) U_ABL = 0.729·[(5m s –1 ) – 0 ] = 3.6 m s –1 V_ABL = 0.729·[0 + (0.61)·(5m s –1 )] = 2.2 m s –1 Use eq. (10.40): M_ABL = [U 2 _ABL + V 2 _ABL ] 1/2 = 4.2 m s –1 α =tan –1 (V_ABL/U_ABL) = tan –1 (2.2/3.6) = 31.4° Check: Physics & units are reasonable. Exposition: Again, drag slows the wind and causes it to cross the isobars toward low pressure. The ABL wind direction is 238.6°.

10.5.4. ABL Gradient (ABLG) Wind

For curved isobars in the atmospheric boundary layer (ABL), there is an imbalance of the following forces: Coriolis, pressure-gradient, and drag. This imbalance is a centripetal force that makes ABL air spiral outward from highs and inward toward lows (Fig. 10.18). An example was shown in Fig. 10.1. If we devise a centrifugal force equal in magnitude but opposite in direction to the centripetal force, then the equations of motion can be written for spiraling flow that is steady over any point on the Earth’s surface (i.e., NOT following the parcel): \(\ \begin 0=-\frac \cdot \frac+f_ \cdot V-w_ \cdot \frac>+s \cdot \frac\tag\end\) \(\ \begin 0=-\frac \cdot \frac-f_ \cdot u-w_ \cdot \frac>-s \cdot \frac\tag\end\) We can anticipate that the ABLG winds should be slower than the corresponding gradient winds, and should cross isobars toward lower pressure at some small angle α (see Fig. 10.19). Lows are often overcast and windy, implying that the atmospheric boundary layer is statically neutral. For this situation, the transport velocity is given by: \(\ \begin w_<\mathrm>=C_ \cdot M=C_ \cdot \sqrt+V^>\tag\end\) Because this parameterization is nonlinear, it increases the nonlinearity (and the difficulty to solve), eqs. (10.43). Highs often have mostly clear skies with light winds, implying that the atmospheric boundary layer is statically unstable during sunny days, and statically stable at night. For daytime, the transport velocity is given by: \(\ \begin w_=b_ \cdot w_\tag\end\) This parameterization for w_B is simple, and does not depend on wind speed. For statically stable conditions during fair-weather nighttime, steady state is unlikely, meaning that eqs. (10.43) do not apply. Nonlinear coupled equations (10.43) are difficult to solve analytically. However, we can rewrite the equations in a way that allows us to iterate numerically toward the answer (see the INFO box below for instructions). The trick is to not assume steady state. Namely, put the tendency terms (∆U/∆t , ∆V/∆t) back in the left hand sides (LHS) of eqs. (10.43). But recall that ∆U/∆t = [U(t+∆t) – U]/∆t, and similar for V. For this iterative approach, first re-frame eqs. (10.43) in cylindrical coordinates, where (U, V) are the (tangential, radial) components, respectively (see Fig. 10.19). Also, use G, the geostrophic wind definition of eq. (10.28), to quantify the pressure gradient. For a cyclone in the Northern Hemisphere (for which s = +1 from Table 10-2), the atmospheric boundary layer gradient wind eqs. (10.43) become: \(\ \begin M=\left(U^+V^\right)^\tag\end\) \(\ \begin U(t+\Delta t)=U+\Delta t \cdot\left[f_ \cdot V-\frac >+s \frac\right]\tag\end\) \(\ \begin V(t+\Delta t)=V+\Delta t \cdot\left[f_ \cdot(G-U)-\frac >-s \frac\right]\tag\end\) where (U, V) represent (tangential, radial) parts for the wind vector south of the low center. These coupled equations are valid both night and day.

Sample Application If G = 10 m s –1 at R = 400 km from the center of a N. Hem. cyclone, C_D = 0.02, z_i = 1 km, and fc = 10 –4 s –1 , then find the ABLG wind speed and components. Find the Answer Given: (see the data above) Find: M_BLG = ? m s –1 , U_BLG = ? m s –1 , V_BLG = ? m s –1 , Use a spreadsheet to iterate (as discussed in the INFO box) eqs. (10.44) & (1.1) with a time step of ∆t = 1200 s. Use U = V = 0 as a first guess.

The evolution of the iterative solution is plotted at right as it approaches the final answer of U_ABLG = 4.16 m s –1 , V_ABLG = 4.33 m s –1 , M_ABLG= 6.01 m s –1 , where (U_ABLG , V_ABLG) are (tangential, radial) parts. Check: Physics & units are reasonable. You should do the following “what if” experiments on the spreadsheet to check the validity. I ran experiments using a modified spreadsheet that relaxed the results using a weighted average of new and previous winds. (a) As R approaches infinity and C_D approaches zero, then M_ABLG should approach the geostrophic wind G. I got U_ABLG = G = 10 m s –1 , V_ABLG = 0. (b) For finite R and 0 drag, then M_ABLG should equal the gradient wind M_tan. I got U_ABLG = 8.28 m s –1 , V_ABLG = 0. (c) For finite drag but infinite R, then M_ABLG should equal the atmospheric boundary layer wind M_ABL. I got U_ABLG = 3.91 m s –1 , V_ABLG = 4.87 m s –1 . Because this ABL solution is based on the full equations, it gives a better answer than eqs. (10.41). Exposition: If you take slightly larger time steps, the solution converges faster. But if ∆t is too large, the iteration method fails (i.e., blows up).

INFO • Find the Answer by Iteration

(1) Make an initial guess for (U, V), such as (0, 0). (2) Use these (U, V) values in the right sides of eqs. (10.44) and (1.1), and solve for the new values of [U(t+∆t), V(t+∆t)]. (3) In preparation for the next iteration, let U = U(t+∆t) , and V = V(t+∆t) . (4) Repeat steps 2 and 3 using the new (U, V) on the right hand sides . (5) Keep iterating. Eventually, the [U(t+∆t), V(t+∆t)] values stop changing (i.e., reach steady state), giving UABLG = U(t+∆t), and VABLG = V(t+∆t). Because of the repeated, tedious calculations, I recommend you use a spreadsheet (see the Sample Application) or write your own computer program. As you can see from the Sample Application, the solution spirals toward the final answer as a damped inertial oscillation.

For daytime fair weather conditions in anticyclones, you could derive alternatives to eqs. (10.44) that use convective parameterizations for atmospheric boundary layer drag. Because eqs. (10.44) include the tendency terms, you can also use them for non-steady-state (time varying) flow. One such case is nighttime during fair weather (anticyclonic) conditions. Near sunset, when vigorous convective turbulence dies, the drag coefficient suddenly decreases, allowing the wind to accelerate toward its geostrophic equilibrium value. However, Coriolis force causes the winds to turn away from that steady-state value, and forces the winds into an inertial oscillation. See a previous INFO box titled Approach to Geostrophy for an example of undamped inertial oscillations. During a portion of this oscillation the winds can become faster than geostrophic (supergeostrophic), leading to a low-altitude phenomenon called the nocturnal jet. See the Atmospheric Boundary Layer chapter for details.

10.5.5. Cyclostrophic Wind

Winds in tornadoes are about 100 m s –1 , and in waterspouts are about 50 m s –1 . As a tornado first forms and tangential winds increase, centrifugal force increases much more rapidly than Coriolis force. Centrifugal force quickly becomes the dominant force that balances pressure-gradient force (Fig. 10.20). Thus, a steady-state rotating wind is reached at much slower speeds than the gradient wind speed. If the tangential velocity around the vortex is steady, then the steady-state force balance is: \(\ \begin 0=-\frac \cdot \frac+s \cdot \frac\tag\end\) \(\ \begin 0=-\frac \cdot \frac-s \cdot \frac\tag\end\) You can use cylindrical coordinates to simplify solution for the cyclostrophic (tangential) winds M_cs around the vortex. The result is: \(\ \begin M_=\sqrt<\frac \cdot \frac>\tag\end\) where the velocity M_cs is at distance R from the vortex center, and the radial pressure gradient in the vortex is ∆P/∆R. Recall from the Gradient Wind section that anticyclones cannot have strong pressure gradients, hence winds around highs are too slow to be cyclostrophic. Around cyclones (lows), cyclostrophic winds can turn either counterclockwise or clockwise in either hemisphere, because Coriolis force is not a factor.

Sample Application A 10 m radius waterspout has a tangential velocity of 45 m s –1 . What is the radial pressure gradient? Find the Answer Given: M_cs = 45 m s –1 , R = 10 m. Find: ∆P/∆R = ? kPa m –1 . Assume cyclostrophic wind, and ρ = 1 kg m –3 . Rearrange eq. (10.46): \(\frac=\frac \cdot M_^=\frac <\left(1 \mathrm/ \mathrm^\right) \cdot(45 \mathrm / \mathrm)^><10 \mathrm>\) ∆P/∆R = 202.5 kg·m –1 ·s –2 / m = 0.2 kPa m –1 . Check: Physics & units are reasonable. Exposition: This is 2 kPa across the 10 m waterspout radius, which is 1000 times greater than typical synoptic-scale pressure gradients on weather maps.

10.5.6. Inertial Wind

Steady-state inertial motion results from a balance of Coriolis and centrifugal forces in the absence of any pressure gradient: \(\ \begin 0=f_ \cdot M_+\frac\tag\end\) where M_i is inertial wind speed, f_c is the Coriolis parameter, and R is the radius of curvature. Since both of these forces depend on wind speed, the inertial wind cannot start itself from zero. It can occur only after some other force first causes the wind to blow, and then that other force disappears. The inertial wind coasts around a circular path of radius R, \(\ \begin R=-\frac\tag\end\) where the negative sign implies anticyclonic rotation (Fig. 10.21). The time period needed for this inertial oscillation to complete one circuit is Period = 2π/f_c, which is half of a pendulum day (see Approach to Geostrophy INFO Box earlier in this chapter). Although rarely observed in the atmosphere, inertial oscillations are frequently observed in the ocean. This can occur where wind stress on the ocean surface creates an ocean current, and then after the wind dies the current coasts in an inertial oscillation.

Sample Application For an inertial ocean current of 5 m s –1 , find the radius of curvature and time period to complete one circuit. Assume a latitude where fc = 10 –4 s –1 . Find the Answer Given: M_i = 5 m s –1 , f_c = 10 –4 s –1 . Find: R = ? km, Period = ? h Use eq. (10.48): R = –(5 m s –1 ) / (10 –4 s –1 ) = –50 km Use Period = 2π/f_c = 62832 s = 17.45 h Check: Units & magnitudes are reasonable. Exposition: The tracks of drifting buoys in the ocean are often cycloidal, which is the superposition of a circular inertial oscillation and a mean current that gradually translates (moves) the whole circle.

10.5.7. Antitriptic Wind

A steady-state antitriptic wind Ma could result from a balance of pressure-gradient force and turbulent drag: \(\ \begin 0=-\frac \cdot \frac-w_ \cdot \frac>\tag\end\) where ∆P is the pressure change across a distance ∆d perpendicular to the isobars, w_T is the turbulent transport velocity, and z_i is the atmospheric boundary-layer depth. This theoretical wind blows perpendicular to the isobars (Fig. 10.22), directly from high to low pressure: \(\ \begin M_=\frac \cdot f_ \cdot G>\tag\end\) For free-convective boundary layers, w_T = b_D·w_B is not a function of wind speed, so M_a is proportional to G. However, for windy forced-convection boundary layers, w_T = C_D·M_a, so solving for Ma shows it to be proportional to the square root of G. This wind would be found in the atmospheric boundary layer, and would occur as an along-valley component of “long gap” winds (see the Regional Winds chapter). It is also sometimes thought to be relevant for thunderstorm cold-air outflow and for steady sea breezes. However, in most other situations, Coriolis force should not be neglected; thus, the atmospheric boundary-layer wind and BL Gradient winds are much better representations of nature than the antitriptic wind.

Sample Application In a 1 km thick convective boundary layer at a location where f_c = 10 –4 s –1 , the geostrophic wind is 5 m s –1 . The turbulent transport velocity is 0.02 m s –1 . Find the antitriptic wind speed. Find the Answer Given: G = 5 m s –1 , z_i = 1000 m, f_c = 10 –4 s –1 , w_T = 0.02 m s –1 Find: M_a = ? m s –1 Use eq. (10.50): M_a = (1000m)·(10 –4 s –1 )·(5m s –1 ) / (0.02 m s –1 ) = 25 m s –1 Check: Magnitude is too large. Units reasonable. Exposition: Eq. (10.50) can give winds of M_a > G for many convective conditions, for which case Coriolis force would be expected to be large enough that it should not be neglected. Thus, antitriptic winds are unphysical. However, for forced-convective boundary layers where drag is proportional to wind speed squared, reasonable solutions are possible.

10.5.8. Summary of Horizontal Winds

Table 10-5 summarizes the idealized horizontal winds that were discussed earlier in this chapter. On real weather maps such as Fig. 10.23, isobars or height contours have complex shapes. In some regions the height contours are straight (suggesting that actual winds should nearly equal geostrophic or boundary-layer winds), while in other regions the height contours are curved (suggesting gradient or boundary-layer gradient winds). Also, as air parcels move between straight and curved regions, they are sometimes not quite in equilibrium. Nonetheless, when studying weather maps you can quickly estimate the winds using the summary table.

* For Northern Hemisphere. Direction is opposite in Southern Hemisphere. ** Antitriptic winds are unphysical; not listed here.

This page titled 10.5: Horizontal Winds is shared under a CC BY-NC-SA 4.0 license and was authored, remixed, and/or curated by Roland Stull via source content that was edited to the style and standards of the LibreTexts platform.
